形状

尺寸(毫米)
(外径*厚度*内径)

规格1

规格2

规格3

规格4

备注

PDT

180*3/6*31.75

WA60-120
K6V127

WA60-120
K8VBE

窄槽成型加工及清角用砂轮,特殊底径要求R0.10-0.05可选用粒度150-320

P

180*6.4*31.75

WA60-120
K6V127

WA60-120
K8VBE

P

180*8*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

较宽面积平面研磨
WA可用于冷作模具钢的研磨:
SKD11,XW-10,XW-41,DL-53

PA可用于塑胶模具钢的研磨:
P-20M,718,738,S136
如要获得较大的进刀,可选用气孔砂轮,规格为25A46-HVCF2

SA可用于热作模具具钢及高速钢的研磨:SKD-61,8402,8407,ASP23,ASP30,ASP60

3SG可用于所有场合,特别是对磨削高速钢和钛合金等硬度较高且难磨的材质可提高磨削效率和精度

P

180*10*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

P

180*13*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

P

180*19*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

PDA

180*25*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

P

205*6.4*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

P

205*8*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

P

205*10*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

P

205*13*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

P

205*19*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

PDA

205*25*31.75

WA46-120
K8VBE

PA46-120
K8VBE

SA46-120
J8VBE

3SG46-60
J8VSZ

B

100*50*20

WA60-120
K8VBE

PA46-120
K8VBE

B

100*50*19.05

WA60-120
K8VBE

PA46-120
K8VBE

BW

75*32*20

WA46-120
K8VBE

PA46-120
K8VBE

BW

100*35*20

WA46-120
K8VBE

PA46-120
K8VBE

BW

125*45*32

WA46-120
K8VBE

PA46-120
K8VBE

BW

150*50*32

WA46-120
K8VBE

PA46-120
K8VBE

D1

75*8*13

WA46-120
K8VBE

PA46-120
K8VBE

D1

100*10*20

WA46-120
K8VBE

PA46-120
K8VBE

D1

125*13*32

WA46-120
K8VBE

PA46-120
K8VBE

D1

150*16*32

WA46-120
K8VBE

PA46-120
K8VBE

D1

200*20*32

WA46-120
K8VBE

PA46-120
K8VBE

形状

尺寸(毫米)
(外径*厚度*内径)

规格1

规格2

备注

P

250*25*75

WA46-60K8VBE

PA46-60K8VBE

WA用于磨削普通碳钢工件
PA用于磨削合金钢和淬火钢工件
粒度选择:46粒可达到Ra1.2-1.6
60粒可达到Ra0.4-0.8

P

300*40*127

WA46-100K8VBE

PA46-100K8VBE

P

305*25.4*76.2

WA46-60K8VBE

PA46-60K8VBE

P

305*25.4*127

WA46-60K8VBE

PA46-60K8VBE

P

305*32*76.2

WA46-60J8VBE

PA46-60J8VBE

P

305*32*127

WA46-60J8VBE

PA46-60J8VBE

WA用于磨削普通碳钢工件
PA用于磨削合金钢和淬火钢工件粒度选择:36粒相对46粒而言可获得较大进刀,平面粗糙度略差于46粒

P

305*38*127

WA46-60J8VBE

PA46-60J8VBE

P

355*38*127

WA46-60J8VBE

PA46-60 H8VBE

P

355*50*127

WA36-46 J8VBE

PA36-46J8VBE

P

405*50*127

WA36-46 J8VBE

PA36-46J8VBE

P

400*50*203

WA46-80K8VBE

PA46-80K8VBE

P

510*50*127

WA36-46J8VBE

PA36-46H8VBE

P

510*75*127

WA36-46J8VBE

PA36-46H8VBE

P

510*75*203.2

WA36-46J8VBE

PA36-46H8VBE

P

510*100*203.2

WA36-46J8VBE

PA36-46H8VBE

砂轮外径尺寸(毫米)
O.D(MM)

粒度
Grit

硬度
Grade

组织号
Structure

结合剂
Bond

*最高转速(米/秒)
M.O.S(m/s)

磨料种类
Abrasives

30-1067

24-120

G-Q

5,6,7,8

VBE

35

A,WA,AWA,SA,PA,ASA
(A,38A,19A,32A,25A,23A)

30-915

24-120

H-P

6,7,8,9

V127

63

A,WA,AWA,SA,PA,ASA
(A,38A,19A,32A,25A,23A)

30-1067

36-120

I-P

7,8

VS

63

A,WA,AWA,SA,PA,ASA
(A,38A,19A,32A,25A,23A)

30-610

36-120

I-R

7,8

V05

60

A,WA,AWA,SA,PA,ASA
(A,38A,19A,32A,25A,23A)

30-610

24-120

I-Q

7,8

V07

50

A

30-762

36-120

D-K

11,12,13

VCF2

45

WA,AWA,SA,PA
(38A,19A,32A,25A)

30-610

24-120

E-M

11,12,13

VBEP

45

WA,AWA,SA,PA
(38A,19A,32A,25A)

30-610

150-400

H-P

10,11

VF

60

WA,SA,PA,
(38A,32A,25A)

30-610

36-120

H-R

7,8

V

45

WA,SA,PA,
(38A,32A,25A)

30-915

46-120

G-MN

6,7,8

V02

45

GC,C
(39C,37C)

30-915

24-220

I-T

2,3,4,5,6,7

VK

45

GC,C
(39C,37C)

30-762

36-120

G-K

8

VKP

40

GC,C
(39C,37C)

30-1067

36-150

H-P

8

VS

63

SG

30-762

36-120

E-K

12

VSP

45

SG
